InJet® 388 CRD is developed primarily for the removal of solder pastes and SMT adhesives from stencils, PumPrints,squeegees and misprints. The cleaning system can also be used for PCB cleaning, or for a combination of PCB cleaning and the afore-mentioned cleaning processes. The machine can also be used for the removal of cured conformal coating.
The InJet® 388 series cleaning systems represent unique vertical Spray-In-Air technology developed and manufactured by DCT.
The vertically installed Spray-In-Air device minimizes the shadowing effect commonly seen in horizontal cleaners, and maximizes the efficiency of the cleaning process as the cleaning fl uid is sprayed directly onto the cleaned component.
1 PROCESS CHAMBER
3 PROCESSES - CLEANING, RINSING, DRYING
- Real-time cleaning fluid pressure monitoring
- Control system of fluids limit pressures
- Liquid and filter replacement notification - cycle counting
- Minimum level warning - cleaning and rinsing fluid
- Conductivity measurement - rinse
Link to cleaning fluids
